| Characteristic name, UM (measuring mode) | Letter symbol | Magnitude |
|---|---|---|
| Switching DC voltage, V | Uком | 28 |
| Voltage transient (for 0,1 с as per GOST Р 54073-2010), V | 65 | |
| Control circuit useful current not more than, mA | Iупр | 100 |
| Switching rated current, А | Iком | 40 |
| Leak current, mA (for Uком= Uком мах) not more than | Iут | 0,1 |
| On-resistance, Ohm not more than | Rоткр | 5 |
| Insolation resistance between current carrying circuits and frame not less than, MOhm | Rиз | 200 |
| Turn on time, ms, not more than | tвкл | 0,3 |
